MDF Center Panel Profiles
The default material for center panels is MDF.
 |
 |
|
MDF-01 flat front panel with 1/8" back reveal
|
MDF-02 3/8" flat panel default 2pc MDF *only available with 2-Piece MDF or framing bead 5pc - P (Bar Harbor) |
|
|
 |
|
MDF-03 beveled raised panel |
MDF-04 ogee raised panel |
 |
 |
|
MDF-05 cove raised panel |
MDF-06 beveled raised panel with shelf |
 |
 |
|
MDF-07 1/4" flat panel default 5pc painted |
MDF-08 reverse bevel |
|
|
|
|
MDF-09 reverse cove |
MDF-10 flat front panel with 1/8" back reveal flush *Actual thickness will depend on door thickness. Designed to be flush with back of cabinet door |
MDF Plywood with Veneer Center Panel Profiles
MDF plywood with veneer center panels are the default for stained doors, typically walnut and white oak, where the customer intends to spray a clear stain on the door instead of paint.
 |
 |
|
VNR-01 1/4" veneer flat panel default 5pc stained |
VNR-02 3/8" veneer flat panel *only available with framing bead 5pc - P (Bar Harbor) |
|
|
|
|
VNR-03 veneer flat front panel with 1/8" back reveal |
|
Solid Wood Center Panel Profiles
|
|
|
WD-01 flat front panel with 1/8" back reveal |
WD-02 3/8" flat panel *only available with framing bead 5pc - P (Bar Harbor) |
 |
 |
|
WD-03 beveled raised panel |
WD-04 ogee raised panel |
|
|
|
WD-05 cove raised panel |
|
